DZ47-63(DC)小型直流断路器用于直流额定电压至1000V，额定电流至63A线路中，起过载和短路保护之用，也可以作为线路的不频繁操作转换之用。

断路器适用于通讯、直流电源、充电桩、光伏系统等直流系统应用场合。

符合标准：GB/T 14048.2、IEC 60947-2，GB/T10963.2（本款产品有两种标准）。

产品附件：OF 辅助触头，SD 报警触头，MX+OF 分励脱扣器，过、欠压脱扣器。

The DZ47-63 (DC) miniature DC circuit breaker is designed for use in circuits with a DC rated voltage up to 1000 V and a rated current up to 63 A, providing overload and shortcircuit protection; it can also be used for non-frequent switching operations of the circuit.

Circuit breakers are suitable for DC system applications such as communications, DC power supplies,charging stations, and photovoltaic systems.

Complies with the following standards: GB/T 14048.2, IEC 60947-2, and GB/T 10963.2 (this product complies with two of these standards).

Product accessories: OF auxiliary contact, SD alarm contact, MX+OF de-energizing trip unit, overvoltage and undervoltage trip unit.
