ZMB6L-125漏电断路器适用于交流50Hz/60Hz，额定电压单极两线，两极230V，三极四线、四极400V，额定电流至125A的线路中，当人身触电或电网泄漏电流超过规定值时，剩余电流动作断路器能够在极短的时间内迅速切断故障电源，保护人身及用电设备的安全，同时可以保护线路和电动机的过载或短路，亦可作为线路的不频繁转换及电动机的不频繁起动之用。

产品符合GB/T16917.1和IEC61009-1标准。

The ZMB6L-125 Residual Current Circuit Breaker is suitable for circuits operating at AC 50Hz/60Hz, with a rated voltage of single-pole two-wire (230V), two-pole four-wire (400V), or four-pole four-wire configurations, and a rated current up to 125A. When a person is electrocuted or when the leakage current in the power grid exceeds the specified threshold, the residual current operated circuit breaker can rapidly disconnect the faulty power supply within an extremely short time, thereby safeguarding both personnel and electrical equipment; it also provides protection against overloads or short circuits in the circuit and motor, and can be utilized for non-frequent circuit switching as well as non-frequent motor starting applications.

The product complies with the GB/T16917.1 and IEC61009-1 standards.
